Product · LED hologram fan

HD-F65 65cm LED Hologram Fan

HD-F65 65cm LED Hologram Fan for Retail, Exhibition and Museum Displays

The HD-F65 is a 65cm LED hologram fan from Shenzhen HDFocus Technology Co., Ltd., a commercial display manufacturer founded in 2014 with its own 3000+ sqm factory, 5 production lines and 10+ QC inspectors. As a mid-size model in the HDFocus hologram fan line, this LED hologram fan projects a 650x650mm floating image with 1600x1600 resolution and a 176° viewing angle, making it suitable for in-store product showcases, exhibition booths, museum installations and event stages. Across the hologram fan line, models feature brushless motors, App/PC/cloud control and multi-unit splicing. The HD-F65 is available as an OEM/ODM project with a MOQ of 1 unit, so buyers can test a single sample unit before scaling to bulk orders.

Key Features

• 650x650mm imaging area — a 65cm fan diameter that produces a large, visible floating image for tripod, floor stand and hanging installations.
• 1600x1600 resolution — for logos, product renders and short branded animations.
• 176° viewing angle — a wide viewing-angle specification for the 650x650mm image.
• 850 LEDs — a dense LED array across the imaging area, with an LED lifetime of 20,000 hours.
• Low power consumption of 10-15W — a 10–15W rated power draw.
• HD-DS software and series-level control options — content is uploaded via the HD-DS software; App, PC and cloud control are available across the hologram fan series.
• Brushless motor and Bluetooth audio — brushless motor drive and Bluetooth audio, features of the hologram fan series.
• Multi-unit splicing and optional acrylic cover — multi-unit splicing is a series capability that links several fans into a wider hologram wall; a round or square acrylic protective cover is available for the HD-F65.

Specifications

Applications

The HD-F65 hologram fan is used in commercial display settings where a single unit needs to attract attention without occupying much floor or counter space. At 2.5KG gross weight and a 58x26x14cm package, it can be deployed across multiple locations within the same chain. Typical uses include product launches, brand animations, menu boards, wayfinding visuals and promotional loops. Because the fan series supports multi-unit splicing, larger installations can start with one fan and expand into a hologram wall when a project requires a wider image.

• Retail stores — in-store displays for new products, limited editions and campaign visuals.
• Exhibitions — booth highlights that draw visitors and loop branded content during show hours.
• Events — stage and entrance displays for launches, conferences and sponsor visibility.
• Museums — indoor interpretive visuals that add motion to artifacts, models and story panels.
• Shopping malls — atrium, corridor and storefront installations for seasonal promotions.

MOQ, Lead Time & After-Sales

HDFocus works with distributors, integrators, retail chains and brand owners, and the ordering process is designed for both trial and volume purchases. As a commercial display manufacturer, the company provides OEM/ODM services for customized projects.

• MOQ: 1 unit. You can order a single HD-F65 to evaluate image quality, software workflow and build quality before committing to a larger program.
• Sample lead time: 1-3 days.
• Bulk order lead time: 7-35 days, depending on quantity and configuration.
• Shipping: DHL, UPS, air freight or sea freight, selected according to destination, weight and required delivery date.
• Factory QC: production runs across 5 production lines with 10+ dedicated QC inspectors, in a 3000+ sqm factory. Certifications for the hologram fan line include CE, FCC and RoHS, and the company holds ISO9001 and ISO14001. Certificates are available upon request.
• Support: HD-DS software guidance and order support from the sales team.

Public sales contacts are Amber You (Sales Director) and Grace Yang (Senior Sales Manager). For technical questions, sourcing requests or OEM/ODM discussions, email [email protected] or call +86-13823645796 / +86-755-85204829.

FAQ

What resolution does the HD-F65 deliver, and what content should I prepare?

The HD-F65 has an imaging area of 650x650mm with a resolution of 1600x1600. Prepare square-format content and confirm the final export settings in the HD-DS software before uploading.

Is the HD-F65 suitable for outdoor use?

The HD-F65 is positioned for commercial display environments such as retail stores, exhibitions, museums, events and shopping malls. For installations exposed to weather, direct sunlight, moisture or heavy dust, contact our team with your site conditions so we can advise on a suitable model and configuration for your project.

How do I upload and manage content?

Content is uploaded using HD-DS software, the control software for the HD-F65. Confirm the final export settings in the software before uploading, and check the file format requirements with the sales team when preparing material.

Can several fans work together as one display?

Yes. Multi-unit splicing is a capability of the hologram fan series, so two or more units can be arranged into a wider hologram wall. This is often used for larger promotional visuals in malls, showrooms and exhibition halls. Units can be ordered first as single samples, then expanded in a later bulk order with the same configuration, and an optional round or square acrylic cover can be added for protection.

Request Factory Price for the HD-F65 LED Hologram Fan

Send your target quantity, destination country and preferred configuration — including whether you need the optional acrylic cover, splicing for multiple units, or OEM/ODM customization — to [email protected], or call +86-13823645796 / +86-755-85204829. Our team will confirm pricing, sample availability and delivery scheduling for your project. Factory address: 5th Floor, 51 Building, Bantian No.3 Industrial Park, Bantian Community, Bantian Street, Longgang, Shenzhen, China.
